INFINITY is an automatic bar feeder designed specifically for Swiss Type lathes.

The full management of the bar loader is entrusted to a PLC touch screen. The electronic interacts with a brushless motor and digital solenoid valves, which set torque and speed of feeding, as well as all the operative functions of the machine.

The steady blocks set in the bar’s channel, are automatically adjusted in only 60 seconds by the PLC, according to the new diameter of the machine.

Technical Features

ROUND BARS

3mm-38mm

8mm-45mm

HEXAGONAL BARS

3mm-33mm

7mm-39mm

SQUARE BARS

3mm-27mm

6mm-32mm

INFINITY S

INFINITY

1200 mm - 3200 mm/1200 mm-4100 mm

BAR LENGTH

60 m/min

FEEDING SPEED

450mm

SEGMENT LENGTH

6.5 - 7.5 bar

AIR PRESSURE
